ENGL E570 (Clean Channel)

New captures of my ENGL E570 with A2 architecture. This time, I will make a full set of all options. It's a very versatile preamp and with many options, you get a lot of sounds. Naming is as follows: Channel (Clean, Crunch, Lead 1 or Lead 2), Modern or Classic mode, Gain Boost (in Clean and Crunch Channels) or High Gain (Lead 1 or 2) followed by the gain setting, Normal Bright (Clean or Crunch) or Contour (Lead 1 or 2), Ultra Bright (Clean or Crunch) or Mid Edge (Lead 1 or 2), MLP (stands for Mega Low Punch) If it doesn't appear in the name, it's not active. For example: "Lead 1, Modern, High Gain 8, Contour" This is Lead 1 channel in modern mode with gain 8 and high gain active, and also contour active. By the way, this is my main rhythm sound. EQ-settings: Clean: Bass 9, Middle 7, Treble 6 Crunch: Bass 9, Middle 7, Treble 7 Lead 1: Bass 8, Middle 5, Treble 8 Lead 2: Bass 8, Middle 5, Treble 7 Signal flow for capturing: ESI Amber i4 --> Palmer Trave reamp Box --> ENGL E570 --> ESI Amber i4 DAW used: Reaper Send Level (input to E570): 6,5dB Return Level: ESI-Input 10 O'Clock Output Level of E570 depending on settings (not relevant to know for usage of the tones). I intend to make gain settings with gain 2, 4, 6, 8 and 10. To make every combination, that's 640 possibilities. Let's see if I can eventually do this. I will separate the channels, because there are too many profiles contained in one tone.
