Electricamp Volume Unit 180 V2 (LTSPICE)

this one actually works I messed up and didn't connect the negative feedback for the first capture (its marked) @+xDBIN means that is the gain the sweep signal had going into the preamp, I ran the sweep signal hot to simulate pedals hitting it hard. I couldn't get the calibration to fix input levels, so just turn it down by the specified amount in the NAM plugin or run a utility before the plugin doing the same thing. the attached video from Fuzzlord was also in the reverb listing where the schematic was, I think it might be the very same amplifier. Check it out for a more in depth demo. In LTSPICE power supply resistors were changed to match specified voltages in the schematic. The schematic is very similar to that of the Matamp GT120, although the power supply is different and it replaces the Presence knob with a Boost knob, which really just controls mids. The drive link has the LTSPICE files so you can capture your own settings on your computer, but just warning you, it may take hours to capture. (You can run multiple simulations in parallel overnight by opening multiple windows) I'd be more than happy to hear from anyone who has more knowledge about LTSPICE than I do on how to optimize my process. 6-26 I reviewed the video and i think I have the Drive and Deep selector positions flipped in the selectors. I have updated the capture names accordingly. Take this into account for the drive files, I uploaded them yesterday. I will correct them soon.
