Suhr SL68 V1

Suhr SL68 set to HV and a crunch tone that works open chords and barre chords. Needs a boost for palm mutes. Update 07/2026 - I recaptured my SL68 with a 5751 in V1 and V3 to strategically desaturate the preamp and PI to get a wider range of clean, edge of break up and driven tones. I kept the PPIMV out of the circuit (maximum), used the HV (120V) PT tap, and set V2 at a level that was just barely on in order to fill out some low end while simultaneously taking advantage of some of the further reduction in gain that comes from jumping the channels. The EQ settings below correspond to the values on the faceplate for each control. CLEAN = P - 8, B - 8, M - 2, T - 8, V1 - 2 EDGE = P - 6, B - 8, M - 4, T - 6, V1 - 4 DRIVE 1 = P - 4, B - 8, M - 4, T - 6, V1 - 6 DRIVE 2 = P - 6, B - 6, M - 6, T - 6, V1 - 6 CRUNCH 1 = P - 8, B - 4, M - 8, T - 8, V1 - 8 CRUNCH 2 = P - 0, BMT V1 All set to MAX Update 03/07/2026 - EVH-Style Capture Added P-0, BMT - MAX, V1 - MAX, V2 - 0, 90V Power Transformer Primary Update 02/26/2026 - Capture Added - Low Gain P-4, BMT- MAX, V1-4, V2-0, Master - MAX, 120V Power Transformer Primary P-4, BMT- MAX, V1-4, V2-0, Master - MAX, 90V Power Transformer Primary Radial Pro RMP and Suhr Reactive Load (unbalanced out) reamp file normalized to -5db peak 2000 epochs 0.003 ESR
